Scientists Can Now 3D Print Tissues Directly Inside the Body—No Surgery Needed

Our bodies are constantly breaking down. Over time, their built-in repair mechanisms also fail. Knee cartilage grinds away. Hip joints no longer support weight. Treatments for breast cancer and other health issues require removal by surgery. Because the body can’t regenerate those tissues, reconstruction using biomaterials is often the only way.

Traditionally, this kind of restoration involves one-size-fits-all breast implants or hip joints. More recently, 3D bioprinted tissues have begun to be tailored for patients. But these artificial tissues are printed outside of the body, and they still require additional surgeries to implant, adding to the chances of scarring, inflammation, or infection, and increasing healing time.

This month, a team from the California Institute of Technology unveiled a system to 3D print tissues inside the body—no surgery needed. Dubbed deep tissue in vivo sound printing (DISP), the system uses an injectable bioink that’s liquid at body temperature but solidifies into structures when blasted with ultrasound. A monitoring molecule, also sensitive to ultrasound, tracks tissue printing in real time. Excess bioink is safely broken down by the body.

In tests, the team 3D printed tissues inside a rabbit’s stomach and mouse’s bladder. They also added conductive nanoparticles to make soft biosensors and depots of medication—anticancer drugs or antibacterial medications—that released their payloads when hit with ultrasound.

“This work has really expanded the scope of ultrasound-based printing and shown its translational capacity,” Yu Shrike Zhang at Harvard Medical School, who was not involved in the research, told IEEE Spectrum. “It’s quite exciting.”

From Light to Sound

Thanks to its versatility, 3D printing has captured the imagination of bioengineers. The technology can be used to make artificial biological tissues, organs, or medical devices.

Bioprinters usually deposit one layer at a time. Each layer is solidified using light, then the next layer is laid on top of it. This layer-by-layer process takes time. More recently, an upgraded method called volumetric printing solidifies 3D structures with a single blast of carefully tailored light. The approach is faster but also constrained by how deeply light can pierce tissues.

Infrared light, for example, can shape implants under a thin layer of skin and muscle, Xiao Kuang at the University of Wisconsin–Madison, who was not involved in the study, wrote in Science. But light dims and scatters the deeper it goes inside the body. This limits the “direct printing of implants beneath millimeter-thick tissues”—or barely below the skin.

Ultrasound, best known for its use monitoring pregnancies, has an advantage here. It can reach deep into organs—nearly eight inches—without damaging them. Scientists have been exploring focused ultrasound, which blasts a certain frequency of soundwaves towards a tissue, as a way to monitor brain and muscle activity.

Ultrasound can also trigger chemical reactions. In 2023, Zhang and colleagues engineered a molecular concoction dubbed “sono-ink” that solidifies when blasted with a specific frequency of sound waves. The team 3D printed multiple shapes inside isolated pork belly, liver, and kidneys and patched tissue damage in a goat heart.

But the ink was sensitive to stress and other disruptions in the body, resulting in slower printing and poor resolution. Sound waves also generate heat, which hardened some of the sono-ink before it had formed the intended structures. Further, other molecules in the ink and local heat spikes across tissues increased biocompatibility risk.

“Ultrasound 3D printing inside a body is more challenging than it seems,” wrote Kuang.

A New Ink

The new system relies on upgraded sono-ink.

The ink has multiple components combined into a single concoction. First up are chains of molecules that normally float about freely but grasp each other when given a molecular cue. These are accompanied by fatty bubbles filled with binder molecules—the molecular cue—that release their payloads when exposed to ultrasound. A final encapsulated component includes multiple chemicals that scatter sound waves and light up when certain soundwaves hit. These help the team visualize the ink’s location and determine if it’s formed the desired structure.

The new setup “prevented premature chemical reactions at body temperature and provided better control of the printing process,” wrote Kuang.

The ink is injected to the target site or shuttled there using catheters. To test the approach, the team 3D printed shapes—stars, pinwheels, teardrops, and lattices—in a variety of tissues, such as thick pork chops and chicken.

Compared to previous light-based methods that only reached fatty tissues, the new technology made it into muscles and more precisely activated the bioink to form shapes. The system works at roughly 40 millimeters a second, the average speed of an inkjet printer.

A Sound Treatment

In mice with bladder cancer, the team 3D printed a kind of depot that slowly released anticancer drugs to stave off cancer growth. Today’s bladder cancer drugs are often flushed away within hours. A bioink patch would concentrate the drugs at the tumor for longer.

In another test, the researchers printed artificial tissue inches below the skin in rabbits’ leg muscles and bellies, showcasing the technology’s ability to restructure tissues in larger animals.

The bioink can also be customized. It can include carbon nanotubes, nanowires, and other biocompatible structures for bioengineering. In one test, the team loaded the ink with conductive nanoparticles and printed electronic sensors to measure the activity of living tissues.

“This functionality could be useful for tests that monitor physiological signals,” wrote Kuang, such as those that monitor heart and muscle health.

The ink is shelf-stable for at least 450 days and doesn’t seem to trigger immune responses. The body eliminates excess ink through normal metabolism or it can be dissolved with a treatment normally used to counter heavy-metal poisoning.

There are still some kinks to iron out. Target tissues differ in depth, shape, and size, which could alter how the ultrasound bounces and cures the bioink. Printing on organs that move—our lungs, heart, and stomach—is even more complex.

In this respect, AI may help, wrote Kuang. Algorithms could decipher the links between sound waves, temperature, materials, and bodily interactions to better simulate and guide printing. An AI-based controller that combines real-time monitoring of the process could rapidly adjust to changes in the body’s status so the bioink solidifies as planned.

Although there’s a ways to go before clinical use, the team says their recent work shows the technology is versatile enough to be widely useful.
